How To Build a Stealth Grow Box Step By Step For Less Than $150


Howdy fellow HMJane-ers! Welcome to your FIRST stealth grow installment with ME, ThisBuds4You!!! I will show you how I made a STEALTH chest of drawers (dresser) for less than $150 and YOU CAN TOO. In 3 months you will be puffin’ on your own homegrown for less than the cost of a half ounce of herb. A little know how, a couple tools and a few items from your neighborhood hardware supplier and you’ll be growing in no time! This box should produce 5-6 ounces of A-Quality bud every grow cycle (60 days). This box also uses only 300 watts of power, about the same amount as a standard desktop computer.

Details About This DIY Grow Box

It took 2 -8 hour days to complete this grow box. This dresser is comprised of 2 growing chambers, 1 for flowering your buds and the other for keeping your mother plant and young clones. The mother plant and clones are kept under 24-18 hours of light and your flowering plants are under 12 hours of light. I used 250 actual watts of power in the flowering chamber. This should give us around 5-6 ounces of bud every grow cycle (60 days) depending on the strain, nutrients, grow medium, etc. Make sure you have good, Dutch quality cannabis seeds to use in this grow as well. I will get into nutrients, caring for your plants, etc in future articles. Alright, enough talk, lets get growing!!!

tools stealth grow box

Tools Needed For The Job

  • Drill & Drill bits (standard sizes)
  • Jigsaw
  • 2″ hole saw drill bit
  • Phillips Screwdriver
  • Rubber mallet or hammer
  • Staple Gun & Staples
  • Tape Measure
  • Sharpie Marker
  • Carpenter’s Knife
  • White caulk, NOT CLEAR
  • Scissors
  • Sandpaper
  • Wood Glue (not necessary, but nice to have)

If you don’t have all the tools, BORROW THEM FROM YOUR FRIENDS & FAMILY! If they ask you why you need them, make up some bullshit! I didn’t want to spend $20 on a hole saw drill bit so I borrowed it, just ask!

Supplies You Will Need To Complete Your Marijuana Grow Box:

  • Dresser – $30
  • 6’x10′ of Panda film – $10
  • 1 – 4’x2′ 0.25″ MDF or Hardboard (I prefer MDF) – $4.50
  • 9 Ceramic light fixtures – $11.43
  • About 8 ft of lamp cord – FREE
  • 3 standard plugs (for lamp cord) – FREE
  • Duct fan (I used a 6″ but a 4″ is also sufficient) – $16.00
  • 3 – 120mm computer fans – $13.50
  • 2 – 80mm (standard) computer fans – FREE
  • 1 standard computer power supply & tester – Power supply FREE, Tester – $12.00
  • 9 CFL bulbs (I used a mix of 42 and 23 watt bulbs) – $35.00
  • 2 Hinges – $2.00
  • 2 Magnetic Closures – $3.00
  • 1 power strip – $2.47
  • 1 piece of plexi glass 3mm thick – FREE
  • 1 thermometer – $10.00
  • 2 timers – $8.00

Misc items (not necessary but nice to have)

  • 8 door/cabinet pulls (not necessary but a very nice touch) – $10
  • 1 carbon scrubber (i got the smallest one CAN FILTER makes) – $39.00 if you are concerned about odor, this is a MUST

Money Saving Tips

1. Re-purpose the wood from inside the dresser! I got an old ass dresser that was probably hand-built by some old pioneer and I was able to reuse a lot of the wood. I only had to purchase 1 new piece of wood (the MDF) for the back door.

2. Get an old junked computer and use the fans and power supply from that, you can probably find one for free, I did.

3. Check the free section of craiglist for dressers, computers, etc. If you can’t find free ones, pretty sure you can find cheap ones. I got my dresser for $30.

4. Don’t pay for lamp cords! Find some old ass lamps in the garbage, free section of craigslist or whatever and use those. Just cut them off from the lamp and wa la!

Disassembling the dresser

Take great care in taking the dresser apart. We took time taking it apart and ended up being able to reuse most of the wood from the dresser. We took apart the drawers and used the bottoms to make the front face that the drawer fronts attached to. We also used the bottom of the drawers for the floors of our new grow box.

Now, I’m not going to get into too much detail from here on out; the pictures are pretty self-explanatory. If you’ve got any questions, feel free to fire away!

Building Your Dresser Grow Box Step-By-Step

Here’s the dresser untouched

grow marijuana dresser

First, we took all the drawers out and began to take those apart with a rubber mallet

grow box plans

Drawer dis-assembly

stealth grow cabinet

Drawer dis-assembly

Here’s the dresser completely gutted (except for the top shelf, I left that in so we could mount the exhaust fans and run the power through there)

stealth grow box 1

Dresser gutted

Then we attached one of the drawer bottoms to the front of the dresser, so we would have something to screw the drawer fronts to

grow box 1

Dresser with support board

Then we attached the drawer fronts with the new drawer handles/pulls

diy grow box 1

Dresser with drawers attached

Once that was completed we cut a 6″ hole on the inside top shelf we left in and we also added a partition wall in the middle with a hole cut out for a 120 mm fan. We also cut holes in the top of our flowering chamber for the 2-120mm fans we will mount there. Be sure to run caulk around the edges on the inside of the dresser so we don’t have an issue with light leaks. I also cut 4 pieces of wood the same depth as the dresser and screwed them into the bottom. These are going to support our new floors.

weed grow box

Boards mounted, holes cut

marijuana grow box

Partition wall with hole cut

Next, make your floors from the scrap drawer bottoms. I drilled holes in them with a 2″ hole saw bit for air flow. Air is your best friend in these small spaces! I lined the floor of the veg room with panda film, I’m making a separate tray to place the plants in the flowering area so I did not line that floor with panda film

grow box for weed

Vegetative chamber floor

grow box weed

Flowering chamber floor

Next, line the entire interior of the dresser with panda film and install the floors

building diy weed grow box

Dresser lined with Panda film

Now, time for the lights. I daisy-chained all the lights together and mounted them to some scrap 1/2″ board I had laying around. You can use pieces of the dresser drawers for this also.

ceramic fixtures for diy grow box

Ceramic fixtures

cannabis grow box lamp

Lamp cord plug

Break time with Sweetwater 420 and Mandala Hashberry

break time

Break Time

Now for the fans, I used 3-120 mm fans. I’m using 2 in the ceiling to exhaust hot air out of the flowering chamber (the lights will be sealed off by a piece of plexi glass), and 1 fan will be blowing air from the flowering chamber into the veg chamber. I powered these fans with a PC power supply. I got a power supply tester so the power supply would power the fans.

diy grow box fans

120mm fans

power supply grow box

Power supply with tester

Now, mount the fans and the lights. I mounted 2-80 mm computer fans in the corners of the flowering box, air flow is our best friend in these small spaces!

lights diy grow box

Lights and fans mounted

Exhaust fans for lights in flowering chamber

chamber lights

PC fans mounted, exhaust fans for flowering chamber lights

Hinges attached to door


Hinges attached

closures weed grow box

Magnetic closures attached

Vegetative chamber up and running!!!

lights for cannabis grow box

Flowering chamber with plexi glass installed

Lights on!

lights on

Flowering chamber with plexi glass installed

Door installed on back of dresser, still need to get a piece of hardboard to attach across the top of the back…

back of weed grow box

Back of dresser

last step

Grow box is done!

front of the dresser

Front of the dresser, DONE!

Any questions, feel free to fire away. Overgrow the world!!!
